7.5x - 50x Stereo Optical Microscope Halogen Lamp A23.1202

Name: 75x 50x Stereo Optical Microscope Halogen Lamp A231202
Brand: CNOEC, OPTO-EDU
Price: 1 USD

7.5x - 50x Stereo Optical Microscope Halogen Lamp A23.1202 Manufactures

Place of Origin : China

Brand Name : CNOEC, OPTO-EDU

Certification : CE|Rohs

Model Number : A23.1202

MOQ : 1 pc

Price : FOB $1~1000, Depend on Order Quantity

Packaging Details : Carton Packing, For Export Transportation

Delivery Time : 5~20 Days

Payment Terms : T/T, West Union, Paypal

Supply Ability : 5000 pcs/ Month

Applications : Industry|Gem

Illumination : Halogen Lamp|LED

product name : stereo zoom microscope

Theory : Stereo Microscope

magnification : 7.5x - 50x

Contact Now

7.5x - 50x Stereo Optical Microscope Halogen Lamp A23.1202

Description:

Stereo Optical Microscope, designed for low magnification observation of a sample, generate three-dimensional, laterally precise images, to see where a three-dimensional view is needed for analyzing the detail. It is ideal for observing large biological samples or analysis of rough materials surfaces, widely used in industry production line, coin & jewelry inspection and etc.

Specifications:

A23.1202 Specification

Model

Eyepiece

Objective

Stand

Working Stage

Incident Illumination

Transmitted Illumination

HWF10X

Zoom
0.75x-5x

Pole

Φ120mm White/Black

Natural Illumination

HWF10X

Pole

Φ95mm Frosted Glass

12V/10W Bowl Halogen Lamp

12V/10W Halogen Lamp

HWF10X

Arm Curved

Φ95mm Frosted Glass

HWF10X

Arm Curved

Φ95mm Frosted Glass

Built-in LED Ring Light

1W LED

Technical Data

		Main Body	with 0.5X Auxi Objective	with 1.5X Auxi Objective	with 2X Auxi Objective
		0.75x-5x	0.375x-2.5x	1.125x-7.5x	1.5X-10x
HWF5X	Total Magnification	3.75x-25x	1.875x-12.5x	5.625x-37.5x	7.5-50x
HWF5X	Field of View	Φ33-Φ5	Φ65-Φ10	Φ22-Φ3.3	Φ16-Φ2.5
HWF10X	Total Magnification	7.5x-50x	3.75x-25x	11.25x-75x	15x-100x
HWF10X	Field of View	Φ33-Φ5	Φ65-Φ10	Φ22-Φ3.3	Φ16-Φ2.5
HWF15X	Total Magnification	11.25x-75x	5.625x-37.5x	16.875x-112.5x	22.5x-150x
HWF15X	Field of View	Φ24-Φ4.2	Φ48-Φ8.5	Φ16-Φ2.8	Φ12-Φ2
HWF20X	Total Magnification	15x-100x	7.5x-50x	22.5x-150x	30x-200x
HWF20X	Field of View	Φ20-Φ3.5	Φ40-Φ7	Φ13.3-Φ2.3	Φ10-Φ1.8
HWF25X	Total Magnification	18.75x-125x	9.375x-62.5x	28.125x-187.5x	37.5x-255x
HWF25X	Field of View	Φ15.8-Φ2.4	Φ31.5-Φ4.8	Φ10.5-Φ1.6	Φ7.9-Φ1.2
Working Distance		113mm	220mm	50mm	35mm
Optional Accessories					Item No.
Eyepiece		HWF5X			A51.1204-05
		HWF10X			A51.1204-10
		HWF15X			A51.1204-15
		HWF20X			A51.1204-20
		HWF25X			A51.1204-25
Auxiliary Objective		0.5X			A52.1281-05
		1.5X			A52.1281-15
		2X			A52.1281-20
