APO Infinity Plan LWD Industry Trinocular DIC Metallurgical Optical Microscope

Place of Origin : China

Brand Name : CNOEC, OPTO-EDU

Certification : CE, Rohs

Model Number : A13.1102

MOQ : 1 pc

Price : FOB $1~1000, Depend on Order Quantity

Packaging Details : Carton Packing, For Export Transportation

Delivery Time : 5~20 Days

Payment Terms : T/T, West Union, Paypal

Supply Ability : 5000 pcs/ Month

Contact Now

APO Infinity Plan LWD Industry Trinocular DIC Metallurgical Optical Microscope A13.1102

A13.1102 Metallurgical Microscope Specification

Head

Compensation Free Trinocular, Inclination of 30 degree,50mm-75mm

Eyepiece

Wide field WF10X/25mm

Wide field WF10X/20mm with crosshair 0.1mm

Infinity Plan Apochromatic Objectives

Infinity Plan Apochromatic Objectives with Long Working Distance

Long Working Distance 35mm PL L5X/0.15.

Long Working Distance 35mm PL L10X/0.28

Long Working Distance 20mm PL L 20X/0.40

Long Working Distance 13mm PL L50X/0.55

Flashboard Filter

Blue Filter

Green Filter

Neutral Filter

Focus System

Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm

Nosepiece

Quadruple, Center Adjustable

Stage

Double Layer Mechanical (Size190mmX140mm,Moving Range:50mmX40mm)

Light Source

12V/50W,AC 85V-230V Halogen Bulb with Apertrue Iris Diaphragm and Field Iiris Diaphragm, Adjustble Brightness

Polarizing Device

Analyzer rotatable 360°, Polarize &Analyzer can be Mmoved in/out of the Optical Path

Checking Tool

0.01mm Micrometer

Optional Accessories

Eyepiece

Micrometer Eyepiece

Objectives

2X

Precision Stage

X-Y Moving Range 25mmX25mm,Moving Precision<5um,Digital Hand Wheel Min Value:0.1um,360°Rotatable Disc

Light Source

Halogen Bulb 12V/100W

Software

Two-dimensional Measurement Software

Professional Metallurgical Iimage Analysis Software

CCD Adapter

0.5X

0.57X

0.75X

Photo Adapter

Photo Adapter

DIC

10X

20X

40X

100X

Planishing Tool

Planishing Tool

CCD Camera

Colour 1/3" High Resolution 520 TV lines

APO Infinity Plan LWD Industry Trinocular DIC Metallurgical Optical Microscope
